Equipment

13 Axis CNC Turn Mill Centers

The unique approach of making complex parts in one set-up, to hold precise true position and manufacture affordable complex parts.

7x Index C200, 3x C100 and 2x G200.2 YB Multi Axis Turn Mill Center Twin Spindle configuration with three turrets for up to 42 live tools. Three tools simultaneiously in cut and with two Y-axis.

  • Bar capacity 2.55" (65mm) at main and counter spindle
  • All machines with automatic barloaders
  • Chuck work possible
  • Axis CNC Turn Mill Centers
    7 Axis CNC Machines Screw

    7 Axis CNC Machines Screw

    Fully automatic screw machine for medium to complex screw machined parts. Simultaneous machining of parts with up to three tools in cut. Optimized turret arrangements for machining parts in short cycle times for ecoomical part manufacturing.

    3x Index ABC Speed Line - Automatic Screw Machine single spindle machine with sub spindle. Two turrets with live tools and 5 back working stations.

  • Bar capacity 2.04" (52mm) at main spindle
  • All machines with automatic barloaders
  • 11 Axis CNC Controlled Sliding Headstock (Swiss) Machine

    Sliding Head Stock (Swiss) machine to make small and long parts. Twin turret arrangement for turn mill center parts. Simultaneous machining of parts with up to three tools in cut.

    2x Traub TNL 18 CNC Swiss Turn Mill Center

  • Bar capacity .787 (20mm) at main and counter spindle
  • Part length up to 27.5” (700mm) long
  • All machines with automatic barloaders
  • Axis CNC Controlled Sliding Headstock
    Heller H2000

    Milling Machines

  • 1x Heller H2000, Horizontal 4 Achse Machining Center
  • 1x Makino PS105, Vertical Machining Center with 4x1Axis Table
  • Metrology Equipment

  • 1x CMM, Mitutoyo CRYSTA-Apex S 7106 700x1000x600mm
  • 1x MarShaft Scope Plus 750/120 Shaft Measuring System
  • 1x MarsurfXR1 –Surface Roughness Measuring Instrument
  • 1x MarSurf CD280 – Contour Measuring Instrument
